9 Tubes:

(2) 6U8
(1) 6BE6
(3) 6AU6
(1) 6BR5 (EM80)
(1) 12AU7
(1) 6X4
-------------------------------
1959 Catalog Description:

This moderately priced tuner features H.H. Scott
wide-band FM design and silver-plated RF circuitry.
The AM section uses H.H. Scott's exclusive wide
range circuitry for reception of high-quality AM
broadcasts.

The beautiful styling complements any decor and perfectly
matches any H.H. Scott amplifier or preamplifier.

Outstanding features include unique tuning and signal
strength indicator, multiplex output, and tape recording
facilities.

Published Technical Specifications:

Sensitivity:
3.0 microvolts for 20 dB of quieting on 300 ohm antenna
terminals.

Circuit Features:
2-megacycle wide-band FM detector assures high selectivity,
ease of tuning and drift-free performance.

Heavily silver-plated RF circuitry. Tuning and signal-strength indicator.
AM section utilizes wide-range detector design for reception
of high fidelity AM broadcasts.

RF stage for both AM and FM sections.

Controls:
Main Tuning; Selector; Level.

Outputs:
Main; Tape Recorder; Multiplex.

Tuning:
Flywheel tuning for quick station selection, logging scale.
