| TYPE |
(Click to see Full-size) |
CONFIGURATION |
YEARS (approx) |
COST NEW ($) |
COMMENTS,
TUBES
(tech notes) |
| 300(A) |
 |
AM/FM-Mono Tuner |
1957-1959 |
$140 |
1st Scott Wide-band AM/FM
Tuner to incorporate "Slide-Rule" Tuning Dial,
6BR5 (EM80) Tuning eye, very similar to 320: but without
front panel level control and multiplex adaptor switching,:
Common AM/FM tuning gang/front-end, (only Scott AM/FM design to use
sidewinder mounted tuning gang)
No
support for Simulcast, as in 330/331
series;
external AM antenna (no rod), MPX output
wide "C"
case/chassis
While the 300/320-series were never very popular, the basic common AM/FM
tuning gang design was sensitive enough to resurface in the very
respectable Type 355 and
380 receivers.
9 Tubes: |
| 320 |
 |
AM/FM-Mono
Tuner |
1959-1960 |
$150 |
Updated Type 300
with improved FM performance
with
"Slide-Rule"
Tuning, 6BR5 (EM80) tuning-eye, added front panel level control,
multiplex/normal switch (for use with 335)
and AM Rod antenna.
No
support for Simulcast, as in 330/331
series, Common AM/FM tuning gang/front-end,
MPX output
wide "C" case/chassis
Early model 320's used 300's 9-tube
design:
Late model 320's used 10 Tubes:
|
| 330(A) |
_tn.JPG) |
AM/FM-Mono
"Simulcast
Stereo"
Tuner |
1955-1956 |
$180 |
1st Scott AM/FM Tuner,
Reception of Simulcast
(AM-Left/FM-Right) Broadcasts, (separate front-ends)
early versions had red plastic dial
pointers, three-way AM Selectivity settings (Wide-Range AM),
Introduced the wide, "C" Case/chassis format, later featured on
the 299 family.
12 Tubes:
|
| 330-B |
 |
AM/FM-Mono
"Simulcast
Stereo"
Tuner |
1957-1958 |
$190 |
Reception of Simulcast
(AM-Left/FM-Right) Broadcasts, (separate front-ends)
Silver-Plated (Modular) Front End Introduced,
three AM Selectivity settings,
used wide "C" Case/chassis.
Rectifier updated.
12 Tubes:
|
| 330-C |
 |
AM/FM-Mono
"Simulcast
Stereo"
Tuner |
1959-1960 |
$220 |
Reception of Simulcast
(AM-Left/FM-Right) Broadcasts, (separate front-ends)
three AM Selectivity settings,
used wide "C" Case/chassis.
AM "rod" antenna added,
12 Tubes: |
| 330-D |
 |
AM/FM-Mono
"Simulcast
Stereo"
Tuner |
1960-1962 |
$220 |
Improved Simulcast
switching functions,
"Stereo" phase reversal
switch added,
front panel updated,
the 330-D was phased out with introduction of the 333 which added true MPX-Stereo.
Used wide "C" Case/chassis,
Note:
6CN7 replaced 6AL5.
12 Tubes:
|
| 331(A) |
_tn.JPG) |
AM/FM-Mono
"Simulcast
Stereo"
Tuner
with Mono Preamp |
1956-1957 |
$260 |
Similar to 330(A)
Addition of
two 12AX7's used in monophonic preamp section accommodating:
Phono (Mag 1/2), Tape and TV (mono)
inputs, Concentric Bass and Treble tone controls, Loudness compensator.
Early versions had
"red plastic dial pointers"
featured I/O-"loop"
jacks for optional outboard noise suppressor
used wide "C" Case/chassis
14 Tubes: |
| 331-B |
 |
AM/FM-Mono
"Simulcast
Stereo"
Tuner
with Mono Preamp |
1957-1958 |
$260 |
Similar to 330-B
Addition of
two 12AX7's used in monophonic preamp section accommodating:
Phono (Mag 1/2), Tape and TV (mono)
inputs, Concentric Bass and Treble tone controls, Loudness compensator.
featured I/O-"loop"
jacks for optional outboard noise suppressor
used wide "C" Case/chassis
14 Tubes: |
| 331-C |
 |
AM/FM-Mono
"Simulcast
Stereo"
Tuner
with Mono Preamp |
1958-1960 |
$260 |
Similar to 330-C
Addition of
two 12AX7's used in monophonic preamp section accommodating:
Phono (Mag 1/2), Tape and TV (mono)
inputs, Concentric Bass and Treble tone controls, Loudness compensator.
featured I/O-"loop"
jacks for optional outboard noise suppressor
used wide "C" Case/chassis
14 Tubes: |
| 333 |
 |
AM/FM-MPX
"Simulcast
Stereo"
with true MPX Stereo |
1962-1963 |
$240 |
True MPX-stereo version of 330-D,
(the 333 has three slide switches, as opposed to the 330's one slide
switch)
Incorporated the "Sonic Monitor" features of the Type 350 FM/MPX
design.
Still accommodated reception of Simulcast
(AM-Left/FM-Right) Broadcasts,
Used selenium
rectifier for B+, eliminating the 6X4 rectifier tube.
Used wide "C" Case/chassis
13 Tubes:
|
| 333-B |
 |
AM/FM-MPX
"Simulcast
Stereo"
with true MPX Stereo |
1964-1965 |
$290 |
Similar to 333 above
Updated Extruded Front
Panel Styling
(Capped or "Pegless" Tuning Knobs),
Dark Brown Tuning Dial
backgrounds,
used wide "C" Case/chassis
13 Tubes:
|
